Benchmarking your application is often a good idea when it comes for fine tuning its performance.

The Golang testing package contains a benchmarking facility that can be used to examine the performance of your Golang code. In this article we’ll see how to write simple benchmark tests that are able to provide us good insights about a given algorithmic solution.

# The good old Fibonacci number calculation

Let’s explore two different implementations: recursive and sequential. We’ll write both unit and benchmark tests for each approach and then we’ll be able to compare them.

# Recursive approach

`package fibofunc RecursiveFibonacci(n uint) uint {    if n <= 1 {        return n    }        return RecursiveFibonacci(n-1) + RecursiveFibonacci(n-2)}`

Each iteration in the series discards the previous results and then re-calculates the intermediate steps for each subsequent iteration.

`package fiboimport "testing"func TestRecursiveFibonacci(t *testing.T) {    data := []struct {        n    uint        want uint    }{        {0, 0},        {1, 1},        {2, 1},        {3, 2},        {4, 3},        {5, 5},        {6, 8},        {10, 55},        {42, 267914296},    }    for _, d := range data {        if got := RecursiveFibonacci(d.n); got != d.want {            t.Errorf("got: %d, want: %d", got, d.want)        }    }}`

It works:

`tiago:~/develop/go/fibonacci/fibo\$ go test -run TestRecursiveFibonacciPASSok  	bitbucket.org/tiagoharris/fibonacci/fibo	1.875s`

# Sequential approach

`package fibofunc SequentialFibonacci(n uint) uint {    if n <= 1 {        return uint(n)    }    var n2, n1 uint = 0, 1    for i := uint(2); i < n; i++ {        n2, n1 = n1, n1+n2    }    return n2 + n1}`

`func TestSequentialFibonacci(t *testing.T) {    data := []struct {        n    uint        want uint    }{        {0, 0},        {1, 1},        {2, 1},        {3, 2},        {4, 3},        {5, 5},        {6, 8},        {10, 55},        {42, 267914296},    }    for _, d := range data {        if got := SequentialFibonacci(d.n); got != d.want {            t.Errorf("got: %d, want: %d", got, d.want)        }    }}`

It also works:

`tiago:~/develop/go/fibonacci/fibo\$ go test -run TestSequentialFibonacciPASSok  	bitbucket.org/tiagoharris/fibonacci/fibo	0.631s`

Notice that we’ve got a considerable performance improvement here; 0.631s versus 1.875s.

# Benchmarking

Writing a benchmark is very similar to writing a test as they share the infrastructure from the testing package. Some of the key differences are:

• Benchmark functions are run several times by the testing package. The value of ‘b.N’ will increase each time until the benchmark runner is satisfied with the stability of the benchmark;
• Each benchmark must execute the code under test b.N times. Thus, a ‘for’ loop will be present in every benchmark function.

Our final fibo_test.go file will contain both unit and benchmark tests:

`package fiboimport (    "testing")func BenchmarkTestRecursiveFibonacci_10(b *testing.B) {    for i := 0; i < b.N; i++ {        RecursiveFibonacci(10)    }}func BenchmarkTestRecursiveFibonacci_20(b *testing.B) {    for i := 0; i < b.N; i++ {        RecursiveFibonacci(20)    }}func BenchmarkTestSequentialFibonacci_10(b *testing.B) {    for i := 0; i < b.N; i++ {        SequentialFibonacci(10)    }}func BenchmarkTestSequentialFibonacci_20(b *testing.B) {    for i := 0; i < b.N; i++ {        SequentialFibonacci(20)    }}func TestRecursiveFibonacci(t *testing.T) {    data := []struct {        n    uint        want uint    }{        {0, 0},        {1, 1},        {2, 1},        {3, 2},        {4, 3},        {5, 5},        {6, 8},        {10, 55},        {42, 267914296},    }    for _, d := range data {        if got := RecursiveFibonacci(d.n); got != d.want {            t.Errorf("got: %d, want: %d", got, d.want)        }    }}func TestSequentialFibonacci(t *testing.T) {    data := []struct {        n    uint        want uint    }{        {0, 0},        {1, 1},        {2, 1},        {3, 2},        {4, 3},        {5, 5},        {6, 8},        {10, 55},        {42, 267914296},    }    for _, d := range data {        if got := SequentialFibonacci(d.n); got != d.want {            t.Errorf("got: %d, want: %d", got, d.want)        }    }}`

We’ll benchmark both recursive and sequential approaches by calculating the sequence for 10 and 20.

With benchmark tests in place, all we need to do is to invoke it via “go test -bench=.”. By default, it runs using all the CPUs available. You can change like this: “go test -cpu=4 -bench=.”.

My machine has 8 CPUs, as we can see by running htop:

Lets run it:

`tiago:~/develop/go/fibonacci/fibo\$ go test -bench=.goos: darwingoarch: amd64pkg: bitbucket.org/tiagoharris/fibonacci/fibocpu: Intel(R) Core(TM) i7-7820HQ CPU @ 2.90GHzBenchmarkTestRecursiveFibonacci_10-8      3534949        335.2 ns/opBenchmarkTestRecursiveFibonacci_20-8        28592      41587 ns/opBenchmarkTestSequentialFibonacci_10-8    372993714          3.221 ns/opBenchmarkTestSequentialFibonacci_20-8    193414836          6.175 ns/opPASSok   bitbucket.org/tiagoharris/fibonacci/fibo 8.406s`

The output format is:

`Benchmark<test-name>-<number-of-cpus> number of executions speed of each operation`

Now we can have a better idea of how the sequential approach is way more efficient than the recursive one:

• BenchmarkTestRecursiveFibonacci10–8 was executed 3,534.949 times with a speed of 335.2 ns/op, while BenchmarkTestSequentialFibonacci10–8 was executed 372,993.714 times with a speed of 3.221 ns/op;
• BenchmarkTestRecursiveFibonacci20–8 was executed 28,592 times with a speed of 41730 ns/op, while BenchmarkTestSequentialFibonacci20–8 was executed 193,414.836 with a speed of 6.175 ns/op.

# Plotting graphics

This is the gnuplot file that will be used to plot a box graphic:

`### gnuplot script to generate a performance graphic.## it expects the following parameters:## file_path - path to the file from which the data will be read# graphic_file_name - the graphic file name to be saved # y_label - the desired label for y axis# y_range_min - minimum range for values in y axis# y_range_max - maximum range for values in y axis# column_1 - the first column to be used in plot command# column_2 - the second column to be used in plot command## Author: Tiago Melo (tiagoharris@gmail.com)### graphic will be saved as 800x600 png image fileset terminal png# allows grid lines to be drawn on the plotset grid# setting the graphic file name to be savedset output graphic_file_name# the graphic's main titleset title "performance comparison"# since the input file is a CSV file, we need to tell gnuplot that data fields are separated by commaset datafile separator ","# disable key boxset key off# label for y axisset ylabel y_label# range for values in y axisset yrange[y_range_min:y_range_max]# to avoid displaying large numbers in exponential formatset format y "%.0f"# vertical label for x values set xtics rotate# set boxplotsset style fill solidset boxwidth 0.5# plot graphic for each line of input fileplot for [i=0:*] file_path every ::i::i using column_1:column_2:xtic(2) with boxes`

This is the benchmark target in our Makefile that runs the benchmark tests and plot graphics for both number of operations and speed of each operation, so we can easily compare them:

`benchmark:    @ cd fibo ; \    go test -bench=. | tee ../graphic/out.dat ; \    awk '/Benchmark/{count ++; gsub(/BenchmarkTest/,""); printf("%d,%s,%s,%s\n",count,\$\$1,\$\$2,\$\$3)}' ../graphic/out.dat > ../graphic/final.dat ; \    gnuplot -e "file_path='../graphic/final.dat'" -e "graphic_file_name='../graphic/operations.png'" -e "y_label='number of operations'" -e "y_range_min='000000000''" -e "y_range_max='400000000'" -e "column_1=1" -e "column_2=3" ../graphic/performance.gp ; \    gnuplot -e "file_path='../graphic/final.dat'" -e "graphic_file_name='../graphic/time_operations.png'" -e "y_label='each operation in nanoseconds'" -e "y_range_min='000''" -e "y_range_max='45000'" -e "column_1=1" -e "column_2=4" ../graphic/performance.gp ; \    rm -f ../graphic/out.dat ../graphic/final.dat ; \echo "'graphic/operations.png' and 'graphic/time_operations.png' graphics were generated."`

First, runs the benchmark tests using a pipe with tee command, which makes it possible to both display the output in the terminal & save it to a file.

Then, we use awk command to parse our file into a CSV format that will be used to plot the graphics. It looks like this:

`1,RecursiveFibonacci_10-8,3579872,334.32,RecursiveFibonacci_20-8,29028,423523,SequentialFibonacci_10-8,375031484,3.2384,SequentialFibonacci_20-8,195996889,6.148`

Next, we call gnuplot two times: 1) generate graphic for number of executions 2) generate graphic for speed of each operation.

Let’s run it:

`tiago:~/develop/go/fibonacci\$ make benchmarkgoos: darwingoarch: amd64pkg: bitbucket.org/tiagoharris/fibonacci/fibocpu: Intel(R) Core(TM) i7-7820HQ CPU @ 2.90GHzBenchmarkTestRecursiveFibonacci_10-8      3579872        334.3 ns/opBenchmarkTestRecursiveFibonacci_20-8        29028      42352 ns/opBenchmarkTestSequentialFibonacci_10-8    375031484          3.238 ns/opBenchmarkTestSequentialFibonacci_20-8    195996889          6.148 ns/opPASSok  	bitbucket.org/tiagoharris/fibonacci/fibo	8.844s'graphic/operations.png' and 'graphic/time_operations.png' graphics were generated.`

Awesome.

Number of operations:

Speed of each operation:

Pretty cool, isn’t it?

# Bonus: calculation of large Fibonacci numbers

`func SequentialFibonacciBig(n uint) *big.Int {    if n <= 1 {        return big.NewInt(int64(n))    }    var n2, n1 = big.NewInt(0), big.NewInt(1)    for i := uint(1); i < n; i++ {        n2.Add(n2, n1)        n1, n2 = n2, n1    }    return n1}`

To test it, here’s our main.go that accepts the desired number as a parameter:

`package mainimport (    "flag"    "fmt"    "bitbucket.org/tiagoharris/fibonacci/fibo")func main() {    var n uint64    flag.Uint64Var(&n, "n", 0, "n")    flag.Parse()    fmt.Printf("%d: %d\n", n, fibo.SequentialFibonacciBig(uint(n)))}`

And here’s our target in Makefile to run it:

`## build: build app's binarybuild:    @ go build -a -installsuffix cgo -o main .## run: run the apprun: build    @ if [ -z "\$(N)" ]; then echo >&2 please set the number via the variable N; exit 2; fi@ ./main -n \$(N)`

Let’s run it for, say, 200:

`tiago:~/develop/go/fibonacci\$ make run N=200200: 280571172992510140037611932413038677189525`

# Conclusion
